AGi-12 series environmentally friendly gas insulated ring network is a fully insulated, green intelligent ring network switchgear independently developed with intelligent design concept. AGi-12 series environmentally friendly gas insulated ring network cabinet has the characteristics of full insulation, long life, maintenance-free, small space occupation, safety and reliability, and no environmental impact. It is widely used in industrial and civil ring networks and terminal power supply. It is particularly suitable for small secondary distribution stations, switchgear, industrial and mining enterprises, airports, railways, commercial areas, high-rise buildings, highways, subways, tunnels and other fields. Especially in special environments such as plateaus, humidity, coldness, and low-lying areas.
The launch of the AGi-12 series of environmentally friendly gas-insulated ring main unit switchgear truly and fully meets the needs of customers such as the State Grid Corporation of China and China Southern Power Grid Corporation for environmentally friendly ring main unit cabinets.
Operating environment
■ Altitude: not more than 2000 meters (if the installation altitude exceeds 2000m, please contact our company).
■ Environmental temperature: maximum temperature +50℃, minimum temperature -45℃, 24h average
temperature does not exceed +35℃.
■ Environmental humidity: 24h average relative humidity does not exceed 95%, monthly average relative humidity does not exceed 90%.
■ Installation environment: There is no explosive and corrosive gas in the surrounding air, and there is no severe vibration and
shock at the installation site.
■ Seismic intensity: 8
Technical features
■ Laser-welded gas box ensures 30 years of maintenance-free.
■ Fully insulated and fully sealed, without any exposed live parts.
■ Environmentally friendly gas is used as protection, which is green and environmentally friendly and does not affect the environment.
■ The three-position disconnector has a visible break, and the inspection and maintenance are safe and reliable.
■ The grounding switch closes quickly and has the ability to close.
■ The micro-positive pressure design can still operate safely under zero gauge pressure.
■ The use of environmentally friendly recyclable materials reduces the impact on the environment.
■ It has a complete mechanical lock, which is simple to operate and safe to use.
■ The modular design makes busbar splicing safe and convenient.
■ Integration and intelligence fully meet the needs of distribution automation.
Reference standards
■ GB/T 3906 3.6kV~40.5kV AC metal-enclosed switchgear and control equipment
■ GB/T 11022 Common technical requirements for high-voltage switchgear and control equipment standards
■ GB 1984 High-voltage AC circuit breakers
■ GB/T 3804 3.6kV~40.5KV high-voltage AC loads
■ GB 1985 High-voltage AC disconnectors and earthing switches
■ GB 3309 Mechanical tests of high-voltage switchgear at room temperature
■ DL/T 404 3.6kV~40.5kV AC metal-enclosed switchgear and control equipment
■ DL/T 402 Technical conditions for ordering high-voltage AC circuit breakers
■ DL/T 486 High-voltage AC disconnectors and earthing switches
■ DL/T 593 Common technical requirements for high-voltage switchgear and control equipment standards
■ GB/T 4208 Enclosure protection grade (IP code)
